Elation PUL345 Pulse Panel FX Strobe Panel Light with 360 Degree Pan / Spin and 180 Degree Tilt

Elation PUL345 Pulse Panel FX Strobe Panel Light with 360° Pan / Spin and 180° Tilt

The Elation PULSE PANEL FX is a powerful strobe panel light designed with customizable RGB and CW strobe effects. Featuring a unique 360° continuous pan/spin movement and 180° tilt, this fixture is perfect for creating dynamic lighting effects in a variety of environments. With advanced control options including DMX, RDM, Art-Net, sACN, and KlingNet protocols, it provides flexibility and ease of use, making it ideal for professional lighting setups. The durable, IP65-rated housing ensures that the fixture performs well in both indoor and outdoor settings.

Features:

• (1152) 1.5W RGB LEDs in 24 zones
• (432) 5W CW strobe LEDs in 48 zones
• (96) 1.5W RGB StrobeLine LEDs in 12 zones
• Fast and continuous 360° pan/spin and 180° tilt
• Art-Net, sACN, and KlingNet support
• IP65-rated for outdoor and indoor use
• Aria x2 wireless device management
• Customizable RGB and CW strobe effects library
• Separate universe control for fixture movement and LED control

Specifications:

• Source: (1248) 1.5W RGB LEDs, (432) 5W CW strobe LEDs
• LED lifespan: 50,000 hours (may vary based on environmental factors)
• Total Lumen Output: 78,265 Lumens (All LEDs), 108,574 Lumens (CW LED), 44,090 Lumens (RGB LED)
• CRI: >70
• Beam Angle: 68°, Field Angle: 112°
• Strobe Rate: 1-20Hz
• Pan/Spin Angle: 540°/360°
• Tilt Angle: 180°
• Control: 12 DMX channel modes (various options from 8ch to 183ch)
• Wireless control: Aria x2, RDM (Remote Device Management)
• Connectivity: IP65 5-pin XLR DMX In/Out, IP65 RJ45 Ethernet In/Out
• Power: IP65 locking power cable, 100-240V, 50/60Hz, Max power consumption 1750W
• Dimensions: Length: 16.54" (420mm), Width: 8.28" (210mm), Height: 15.59" (396mm)
• Weight: 38.58 lbs. (17.5kg)
• Operating temperature: -4°F to 113°F (-20°C to 45°C)
• BTU/hr: 5967.5
