The Story

Antari DMX Merger DIN Rail DMX Merger - 6 Input and 1 Output

The DmxMerger is a tool for combining signals from multiple lighting controllers into a single DMX network. Up to six different DMX signals can be merged together.

Specifications:

  • 6 Inputs
  • Optical Isolation (individual per port)
  • USITT DMX512-A (ANSI E1.11)
  • Screws connectors
  • DIN Rail mounting
  • Power consumption 9-24V DC 500mA power input (optional external PSU)
  • Dimensions 105 x 86 x 60 mm (4.1 x 3.4 x 2.4 inches)
  • Weights 120 gram (0.26 lbs)
Antari DMX Merger DIN Rail DMX Merger - 6 Input and 1 Output - Image 2

Details & Craftsmanship

Every detail has been carefully considered to bring you the perfect product.

Description

Antari DMX Merger DIN Rail DMX Merger - 6 Input and 1 Output

The DmxMerger is a tool for combining signals from multiple lighting controllers into a single DMX network. Up to six different DMX signals can be merged together.

Specifications:

  • 6 Inputs
  • Optical Isolation (individual per port)
  • USITT DMX512-A (ANSI E1.11)
  • Screws connectors
  • DIN Rail mounting
  • Power consumption 9-24V DC 500mA power input (optional external PSU)
  • Dimensions 105 x 86 x 60 mm (4.1 x 3.4 x 2.4 inches)
  • Weights 120 gram (0.26 lbs)
